código parte cl-p116-al12sw-a
compatibilidad intel: lga 1851/1700/1200/1156/1155/1151/1150
amd: am5/am4/fm2/fm1/am3+/am3/am2+/am2
dimensiones 122 x 61 x 156,2 mm (largo x ancho x alto)
material del disipador de calor aletas de aluminio
tubos de calor de cobre
tubo de calor f6 mm x 4 piezas
dimensión del ventilador 120 x 120 x 25 mm (largo x ancho x alto)
cantidad de fans 1 pieza
velocidad del ventilador pwm 800 ~ 1800 rpm
voltaje nominal 12 v
voltaje de arranque 6,0 voltios
corriente nominal 0,3 a
entrada de potencia 4,32w
flujo de aire 62,72 pies cúbicos por minuto
presión estática 1,47 mm h2o
ruido acústico 25,0 dba
tiempo de vida/tiempo de vida del fan 30.000 horas
conexión de pin conector rgb de 5 v
2510 – 4 pines
potencia de enfriamiento 170w
compatibilidad
intel lga1851/1700/1200/1151/1150/1155/1156
am5 / am4
tdp 230 w
dimensión general
120 × 98 × 152 mm (largo × ancho × alto)
material del disipador de calor
tubo de calor de 4×?6 mm (contacto directo) + aleta de aluminio
peso 900 g (disipador de calor + ventilador)
dimensión del ventilador
120 × 120 × 25 mm
velocidad del ventilador 500 ± 200 ~ 2000 ± 10 % rpm
flujo de aire máximo 78,25 pies cúbicos por minuto
presión estática máxima 2,68 mm de h2o
ruido 29,85 db(a) máx.
voltaje nominal 12 v cc (pwm de 4 pines)
voltaje de funcionamiento 10,8 ~13,2 v cc
voltaje iniciado 7 v cc
corriente nominal 0.25a
entrada de potencia 3w
tipo de rodamiento fdb
conector pwm de 4 pines
ean 6931393306223
En stock para entrega inmediata
compatibility intel lga1851/1700/1200/115x amd am5/am4
tdp 220w
overall dimension 127×78×152mm (l×w×h)
heatsink material 4×?6mm heatpipe(hdt)+aluminum fin
weight 750g (heatsink+fan)
fan model af-125-k
fan dimension 120×120×25mm (1 pc)
fan speed 500 ~ 2000±10% rpm
max. air flow 78.25cfm
max. static pressure 2.68mmh2o
noise 29.85db(a) max.
rated voltage 12vdc
operating voltage 10.8 ~ 13.2vdc
started voltage 7vdc
rated current 0.25a
power input 3w
bearing type fdb
connector 4pin pwm
En stock para entrega inmediata
cpu socket
• intel® lga 1700 – 1200 – 1151 – 1150 – 1155 – 1156 socket
• amd® am5 – am4 socket
• exterior color black
• dimensions (l x w x h) 125 x 74 x 152 mm
• heat sink material 4 heat pipes – direct contact – aluminum fins
• dimensions (l x w x h) 120 x 120 x 25 mm
• profile addressable gen 2 rgb
• fan quantity 1 pc
• fan speed 690~2500 ± 10-por-ciento rpm
• fan airflow 70.7 cfm (max)
• fan pressure 3.61 mmh2o (max)
• fan mttf >160000 hours
• fan noise level 32.8 dba (max)
• bearing loop dynamic bearing
• fan power connector 4-pin (pwm)
• rated voltage 12 vdc
• fan rated current 0.2a
• rated current 0.2a
• power consumption 2.4w
• heatpipes 4
type
cpu cooling fans
color
black
model
astria 200
led
addressable rgb
compatibility intel lga1851/1700/1200/115x amd am5/am4
tdp 250w
overall dimension 128×94×151mm (l×w×h)
heatsink material 6×?6mm heatpipe + copper base + aluminum fin
weight 900g (heatsink+fan)
fan dimension 120×120×25mm
fan speed 500 ~ 2000±10% rpm
max. air flow 78.25cfm
max. static pressure 2.68mmh2o
noise 29.85db(a) max.
rated voltage 12vdc (4pin pwm)
operating voltage 10.8 ~ 13.2vdc
started voltage 7vdc
rated current 0.25a
power input 3w
bearing type fdb
connector 4pin pwm
En stock para entrega inmediata
compatibility:
intel lga1700/1200/1151/1150/1155/1156
amd am5/am4
tdp: 270w
overall dimension: 120×140×154mm (l×w×h)
heatsink material: 6×?6mm heatpipe + copper base + aluminum fin
weight: 1190g (heatsink+fan)
fan dimension: 120×120×25mm (2pcs)
fan speed: 500±200 ~ 2000±10% rpm
max. air flow: 78.25cfm
max. static pressure: 2.68mmh2o
noise: 29.85db(a) max.
rated voltage: 12vdc (4pin pwm)
operating voltage: 10.8 ~ 13.2vdc
started voltage: 7vdc
rated current: 0.25a
power input: 3w
bearing type: fdb
connector: 4pin pwm
ean: 6931393305646
En stock para entrega inmediata
compatibilityintel lga1851/1700/1200/115x amd am5/am4
tdp 260w
overall dimension 120×142×157mm (l×w×h)
heatsink material 6×?6mm heatpipe + copper base + aluminum fin
weight 1190g (heatsink+fan)
fan model as-120-argb-w
fan dimension 120×120×25mm (2pcs)
fan speed 300±200 ~ 2000±10% rpm
max. air flow 58cfm
max. static pressure 1.94mmh2o
noise 27.2db(a) max.
rated voltage 12vdc
operating voltage 10.8 ~ 13.2vdc
started voltage 7vdc
rated current 0.15a
power input 1.8w
bearing type hydraulic bearing
connector 4pin pwm / 5v 3pin argb
En stock para entrega inmediata
