compatibility
intel lga1851/1700/1200/115x
amd am5/am4
tdp 180w
overall dimension 120×72×152mm (l×w×h)
heatsink material 4×?6mm heatpipe + copper base + aluminum fin
weight 550g (heatsink+fan)
fan dimension 120×120×25mm
fan speed 500~ 1500±10% rpm
max. air flow 64.8cfm
max. static pressure 1.87mmh2o
noise 26.6db(a) max.
rated voltage 12vdc (4pin pwm)
operating voltage 10.8 ~ 13.2vdc
started voltage 7vdc
rated current 0.28a
power input 3.36w
bearing type hydraulic bearing
connector 4pin pwm
