type
intel form factor atx 12v v3.0 (compatible with atx 3.1)
pfc
active pfc (>0.9 typical)
input voltage
100-240 vac (full range)
input current
12-6a
input frequency
60-50 hz
output capacity
850w
dimension
150 x 140 x 86mm
fan type
120mm fluid dynamic bearing (fdb) fan
80 plus
platinum
efficiency
92% at typical load
mtbf
>100,000 hours
protection
ovp/opp/scp/uvp/ocp/otp
power good signal
100-150ms
hold up time
>16ms
cable type
flat, all black
connectors
atx/mb 20+4 pin x 1 : 650mm*1
cpu/eps 4+4 pin x 2 : 700mm*2
pci-e 16 pin x 1: 700mm*1
pci-e 6+2 pin x 6 : 650mm+150mm*2, 750mm*2
sata x 8 : 600mm+150mm+150mm+150mm*2
4 pin peripheral x 4 : 500mm+150mm+150mm+150mm*1
