la serie mag lucha junto a los jugadores en busca del honor.
con elementos adicionales de inspiración militar en estos productos de juego, renacieron como el símbolo de robustez y durabilidad.
chipset: amd b650
cpu support: supports amd ryzen™ 7000 series desktop processors
socket: am5
memory: 4x ddr5, maximum memory capacity 128gb
memory support ddr5 6600+(oc)/ 6400(oc)/ 6200(oc)/ 6000(oc)/ 5800(oc)/ 5600(oc)/ 5400(oc)/ 5200(oc)/ 5000(oc)/ 4800(jedec) mhz
onboard graphics:
support hdmitm 2.1 with hdr, maximum resolution of 4k 60hz*
support dp 1.4, maximum resolution of 8k 60hz*
*available only on processors featuring integrated graphics. graphics specifications may vary depending on the cpu installed.
1x hdmi™
1x displayport
expansion slot: 2x pci-e x16 slot
support x16/ x4
1x pci-e x1 slot
pci_e1 pcie 4.0 supports up to x16 (from cpu)
pci_e2 pcie 4.0 supports up to x2 (from chipset)
pci_e3 pcie 3.0 supports up to x1 (from chipset)
storage 3x m.2 slot
m.2_1 (from cpu) supports up to pcie 4.0 x4 , supports 2280/2260 devices
m.2_2 (from cpu) supports up to pcie 4.0 x4 , supports 2280/2260 devices
m.2_3 (from chipset) supports up to pcie 4.0 x4 , supports 2280/2260 devices
6x sata 6g port
raid: supports raid 0, raid 1, and raid 10 for sata storage devices*
supports raid 0 and raid 1 for m.2 nvme storage devices
* sata_a1_a2 do not support raid function.
usb: 2x usb 2.0 (rear)
4x usb 2.0 (front)
4x usb 3.2 gen1 type a (rear)
2x usb 3.2 gen1 type a (front)
3x usb 3.2 gen2 type a (rear)
1x usb 3.2 gen2 type c (front)
1x usb 3.2 gen2x2 type c (rear)
lan: realtek® rtl8125b 2.5gbps lan
wireless / bluetooth: amd wi-fi 6e
the wireless module is pre-installed in the m.2 (key-e) slot
supports mu-mimo tx/rx
supports 20mhz, 40mhz, 80mhz,160mhz bandwidth in 2.4ghz/ 5ghz or 6ghz* bands
supports 802.11 a/ b/ g/ n/ ac/ ax
supports bluetooth® 5.2**
* wi-fi 6e 6ghz may depend on every country’s regulations and will be ready
