materials – front panel tempered glass
material – side panel (left) tempered glass
material – side panel (right) steel
dimensions (l x w x h) 425 x 285 x 400 mm (incl. protrusions), 420 x 285 x 380 mm (excl. protrusions)
volume 48.45 l (liters incl. protrusions)
motherboard support itx / micro-atx / atx
expansion slots 7
5.25" drive bays 0
3.5" drive bays 1 (max. 2)
2.5" drive bays 2 (max. 3)
i/o panel – usb ports 1 x usb type c 20gbps, 2 x usb 3.0
i/o panel – audio in / out 1x 3.5mm combo
pre-installed fans – rear 1x 120mm argb pwm
pre-installed fans – side mount 3x 120mm argb pwm reverse fan
fan support – top 2x 140mm / 3x 120mm
fan support – rear 1x 120mm
fan support – side mount 2x 140mm / 3x 120mm
fan support – bottom 3x 120mm
radiator support – top 120 / 240 / 280 / 360mm
radiator support – bottom 120 / 240 / 360mm
radiator support – side mount 120 / 240 / 280mm
clearance – cpu cooler 160mm
clearance – psu 240mm
clearance – graphics card 410mm
power supply support atx
