procesador
lga1851 socket: support for intel® core™ ultra processors
(go to gigabyte’s website for the latest cpu support list.)
l3 cache varies with cpu
chipset
intel® b860 express chipset
memoria
support for ddr5 9066(o.c)/8800(o.c) /8600(o.c) / 8400(o.c) /8266(o.c) / 8200(o.c) / 8000(o.c) / 7950(o.c) / 7900(o.c) / 7800(o.c) / 7600(o.c.) / 7400(o.c.) / 7200(o.c.) / 7000(o.c.) / 6800(o.c.) / 6600(o.c.) /6400/5600 mt/s memory modules
4 x ddr5 dimm sockets supporting up to 256 gb (64 gb single dimm capacity) of system memory
dual channel memory architecture
support for ecc un-buffered dimm 1rx8/2rx8 memory modules (operate in non-ecc mode)
support for non-ecc un-buffered dimm 1rx8/2rx8/1rx16 memory modules
support for extreme memory profile (xmp) memory modules
(the cpu and memory configuration may affect the supported memory types, data rate (speed), and number of dram modules, please refer to "memory support list" on gigabyte’s website for more information.)
gráficos integrados
integrated graphics processor-intel® hd graphics support:
1 x hdmi port, supporting a maximum resolution of 4096×2160@60 hz
support for hdmi 2.1 version and hdcp 2.3.
2 x displayport, supporting a maximum resolution of 3840×2160@144 hz
support for displayport 2.1 version.
(graphics specifications may vary depending on cpu support.)
support for up to triple-display at the same time
audio
realtek® audio codec
high definition audio
2/4/5.1/7.1-channel
you can change the functionality of an audio jack using the audio software. to configure 7.1-channel audio, access the audio software for audio settings.
lan
realtek® 2.5gbe lan chip (2.5 gbps/1 gbps/100 mbps)
wireless communication module
intel® wi-fi 6e ax211 (pcb rev. 1.0)
wifi a, b, g, n, ac, ax, supporting 2.4/5/6 ghz carrier frequency bands
bluetooth 5.3
support for 11ax 160mhz wireless standard
realtek® wi-fi 6e rtl8852ce (pcb rev. 1.1)
wifi a, b, g, n, ac, ax, supporting 2.4/5/6 ghz ca
