chipset
intel z890.
cpu
supports intel core ultra processors (series 2).
lga 1851.
memoria
4x ddr5 udimm, maximum memory capacity 256gb.
memory support 9200 – 6400 (oc) mt/s / 6400 – 4800 (jedec) mt/s.
max. overclocking frequency:
• 1dpc 1r max speed up to 9200+ mt/s.
• 1dpc 2r max speed up to 7200+ mt/s.
• 2dpc 1r max speed up to 4800+ mt/s.
• 2dpc 2r max speed up to 4800+ mt/s.
supports intel por speed and jedec speed.
supports memory overclocking and intel® xmp 3.0.
supports dual-controller dual-channel mode.
supports non-ecc, un-buffered memory.
supports cudimm.
gráficos integrados
1x hdmi.
support hdmi™ 2.1, maximum resolution of 4k 60hz.
1x displayport.
support displayport 1.4, maximum resolution of 4k 60hz.
1x type-c displayport.
thunderbolt 4 ports, supporting displayport 1.4 over usb type-c, with a maximum resolution of 4k 120hz / 8k 60hz.
ranura
3x pci-e x16 slot.
1x pci-e x1 slot.
pci_e1 gen pcie 5.0 supports up to x16 (from cpu).
pci_e2 gen pcie 4.0 supports up to x1 (from chipset).
pci_e3 gen pcie 4.0 supports up to x4 (from chipset).
pci_e4 gen pcie 4.0 supports up to x4 (from chipset).
audio realtek alc897 codec.
7.1-channel high definition audio.
raid
supports raid 0, raid 1, raid 5 and raid 10 for sata storage devices.
supports raid 0, raid 1, raid 5 and raid 10 for m.2 nvme storage devices.
lan inalámbrica y bluetooth
intel killer be1750x wi-fi 7.
the wireless module is pre-installed in the m.2 (key-e) slot.
supports mu-mimo tx/rx, 2.4ghz / 5ghz / 6ghz* (320mhz) up to 5.8gbps.
supports 802.11 a/ b/ g/ n/ ac/ ax/ be.
supports bluetooth 5.4, mlo, 4kqam.
